Piston kit 65.50mm BORE 65.43 Wossner  8281D150 (+1.50mm) SUZUKI
TS185 74-77,
TC185 71-81,
DS185 78-80, Wossner forged pistons are superior in strength and design. Engineered to provide the best possible path for combustion chamber heat transfer to cylinder walls. Elliptically designed to provide a more uniform bearing surface under piston heat expansion, eliminating localized pressure and distributing thrust loads more evenly, thereby preventing piston collapse. Made in Germany. Part No. 56-W922_150.WO Wossner Piston SUZUKI TS185 74-77, TC185 71-81, DS185 78-80 (8281D150)
Circlip P/N CW16
Pin P/N WP027
Ring Set P/N RSB6550 x 2
Size. 65.50mm Display (cm3) 185
Hub stroke (mm) 57.00
Clearance (mm) 0.07
Wossner compression Ratio: 2 stroke
OEM Compression ratio: 2 stroke
Dome volume (cm3) -
Compression height (mm) 32.00
Theorectical weight (G)
