Piston kit 68.25mm Bore 68.19 Wossner 8157D125 (+1.25)
SUZUKI
RM250 1987 - 1988,
Wossner forged pistons are superior in strength and design. Engineered to provide the best possible path for combustion chamber heat transfer to cylinder walls. Elliptically designed to provide a more uniform bearing surface under piston heat expansion, eliminating localized pressure and distributing thrust loads more evenly, thereby preventing piston collapse. Made in Germany Part No. 56-W558+125.WO
Wossner Piston Suzuki RM250 68.25 mm Bore (PN# 8157D125)
Lock P/N CW18
Pin P/N WP033
Ring Set P/N RSB6825
Rod P/N P2027 Display (cm3) 246
Hub stroke (mm) 70.00
Clearance (mm) 0.06
Wossner compression Ratio: 2 stroke
OEM Compression ratio: 2 stroke
Dome volume (cm3)
Compression height (mm) 37.00
Theorectical weight (G)
