This top end piston kit is for Suzuki LT500R models from 1988 to 1990 and includes a 0.5 mm oversize forged piston, the required top end gaskets, and a wrist pin bearing. The kit is supplied as a complete set for top end service, and the kit price includes a 10% discount compared with purchasing the individual items separately.

Features

• Complete top end kit
• Forged piston manufactured in Germany
• MOS2-coated piston for break-in
• Includes cylinder head gasket
• Includes cylinder base gasket
• Includes intake gasket
• Includes exhaust pipe gasket
• Includes cylinder cover gasket
• Includes wrist pin bearing

Specifications

• VintCo Part Number: KTS30-0.5
• Piston size: 86.5 mm
• Oversize: 0.5 mm over
• Piston measurement: 86.41 mm
• Clearance: 0.09 mm

Cross-Reference OEM Part Numbers

• Cylinder Head Gasket: 11141-43B30
• Cylinder Base Gasket: 11241-43B10
• Intake Gasket: 13156-01C10
• Exhaust Pipe Gasket: 14181-43B01
• Cylinder Cover Gasket: 11233-01C00

Vehicle Fitments

• 1988 Suzuki LT500R
• 1989 Suzuki LT500R
• 1990 Suzuki LT500R
