This VintCo top end piston kit is designed for the 1986 Suzuki RM125 and provides the main components required for a top end rebuild, including a forged piston made in Germany with MOS2 coating for break-in, the necessary gaskets and a wrist pin bearing. The kit price reflects a 10% discount compared with purchasing the items individually.

Features

• Complete top end piston kit
• Includes a forged piston made in Germany
• MOS2-coated piston for break-in
• Includes cylinder head gasket
• Includes cylinder base gasket
• Includes reed valve gasket
• Includes cylinder cover gasket
• Includes exhaust pipe gasket
• Includes wrist pin bearing
• Kit price includes a 10% discount over individual items

Specifications

• VintCo Part Number: KTS18-00
• Standard size: 54.00 mm
• Piston measurement: 53.94 mm
• Clearance: 0.06 mm

Cross-Reference OEM Part Numbers

• Cylinder Head Gasket: 11141-01B01-H17
• Cylinder Base Gasket: 11241-01B00-H17
• Reed Valve Gasket: 13156-14500-H17
• Cylinder Cover Gasket: 11233-01B00-H17
• Exhaust Pipe Gasket: 14181-40200-H17

Vehicle Fitments

• 1986 Suzuki RM125
