Piston kit 57mm Bore 56.94 Wossner 8202D100 (+1.00)
KAWASAKI
KX125 1978 - 1981,
Wossner forged pistons are superior in strength and design. Engineered to provide the best possible path for combustion chamber heat transfer to cylinder walls. Elliptically designed to provide a more uniform bearing surface under piston heat expansion, eliminating localized pressure and distributing thrust loads more evenly, thereby preventing piston collapse. Made in Germany Part No. 56-W438.100.WO
Kawasaki KX 125 1978-1981 Wossner Piston 8202D100
Cross reference numbers ONLY. Wiseco 438M05700,
Other Parts.
Lock P/N CW16,
Pin P/N WP036,
Ring Set P/N RSB5700 X 2
CONNECTING Rod KIT P/N P2037 Display (cm3) 125
Hub stroke (mm) 50.50
Clearance (mm) 0.06
Wossner compression Ratio: 2 stroke
OEM Compression ratio: 2 stroke
Dome volume (cm3)
Compression height (mm) 29.70
Theorectical weight (G)
