The Mikuni VM38-9 is a 38mm round slide carburettor from the VM series, designed for universal application across motorcycles, ATVs, and UTVs. This unit is a direct replacement for OEM components, built to strict manufacturing standards for consistent performance and reliability. It includes factory pre-set jets and components, eliminating the need for additional modifications.

Features:

• Round slide VM series carburettor
• Universal application for motorcycles, ATVs, and UTVs
• Direct OEM replacement
• No additional modifications required
• Manufactured to OEM or higher standards

Specifications:

• Bore Size: 38mm
• Intake Side Inner Diameter: 38mm
• Intake Side Outer Diameter: 43mm
• Air Filter Bracket Outer Diameter: 62mm
• Main Jet: 330
• Pilot Jet: 30
• Needle Jet: Q-2 166
• Throttle Valve: 2.5 (VM38/24)
• Jet Needle: 6DP1
• Air Jet: 0.5
• Needle Valve: 3.3 (VM34/39)

Cross-Reference OEM Part Numbers:

• VM38-9

Vehicle Fitment:

YAMAHA

• Kodiak 700 YFM700K 4WD
• Grizzly 700 YFM700FG 4WD FI 2007-2013
• Grizzly 700 YFM700D 4WD FI 2014-2015
• Grizzly 700 YFM700FG 4WD FI 2007-2013
• Grizzly 700 YFM700P 4WD FI 2014-2015
• Grizzly 700 YFM700GP 4WD 2019
• Grizzly 700 YFM700FG 4WD Special Edition 2007-2008
• Grizzly 700 YFM700FG 4WD Edition FI 2007-2008
• Grizzly 700 YFM700FG 4WD FI Edition 2009
• Grizzly 700 YFM700FG 4WD FI Edition 2007-2013
• Grizzly 700 YFM700PH 4WD FI Edition 2014-2015
• Grizzly 700 YFM7000GP 4WD Edition 2019-2021
• Grizzly 700 YFM700FG 4WD FI Edition 2009-2013
• Grizzly 700 YFM700DH Edition 4WD FI 2014-2015
• Grizzly 550 YFM550FG 4WD FI 2009-2010
• Grizzly 550 YFM550FG 4WD 2011-2013
• Grizzly 550 YFM550DE 4WD FI 2014
• Grizzly 550 YFM550FG 4WD IF 2009-2013
