The Mikuni TM38 Carburettor Repair Rebuild Kit is designed for servicing and rebuilding TM-series carburettors, ensuring proper fuel delivery and consistent engine performance. Manufactured to high standards, this kit includes components compatible with various TM32, TM34, TM36, and TM38 models, offering a direct OEM replacement for worn or damaged parts.

Features

• Unmatched reliability and performance from high-tech materials
• Manufactured to exacting standards for confident engine rebuilding
• Direct OEM replacement
• Visual confirmation recommended before ordering
• Easy to install; professional assistance recommended if unsure

Package Included

• 1 x Repair kit

Cross-Reference OEM Part Numbers

• NEEDLE, JET (6DH6-3): 13383-43B00
• E RING: 13394-10010
• FLOAT: 13252-18620
• SCREW: 02112-05206, 02112-0520B
• GASKET: 13251-14300
• RING: 13387-14310, 13387-14230
• ADJUSTER: 13267-48700
• JET, NEEDLE (O-6): 09494-00575
• SPRING: 13268-48110
• JET, PILOT (30): 09492-30003, 09492-30006
• SCREW, AIR (1 1/2): 13269-46010, 13269-95110
• GASKET, TOP: 13266-14300

Vehicle Fitments

• Mikuni TM38-85
• Mikuni TM38-86
• TM32, TM34, TM36, Early TM38 (Float: VM24/236)
• TM32, TM34, TM36, TM38 (Needle Jet: 785-24001-Q-2)
• TM32, TM34, TM38 (Idle Adjusting Screw: 603-16003)
• TM32, TM34, TM38 (Spring, Idle Adjuster: VM24/556)
• TM32, TM34, TM38 (O-Ring, Idle Adjuster: BV32/04)
• TM32, TM34, TM36, TM38 (Air Mixture Screw, Pilot: VM24/622)
• Spring: M12F/46a
• Float Pin: VM30/160
• TM38-85, TM38-86 (Ring, Main Jet: TM34/36)
• TM32, TM34, TM38 (Screw With Lockwasher: CW2=0516)
• TM36, TM38 (Throttle Spring: 730-16003)
• 6 Series Jet Needle: 6 Series
• Pilot Jet: VM22/110-#45
• Main Jet: 4/042-#250
