Rack and Pinion End Kit - Right Hand Side - 0430-0741 ALLBALLS 51-1047-R

UTV steering rack rod ends save customers hundreds of dollars on the cost of a complete steering rack assembly. The inner rod assemblies have increased shaft diameters for improved strength. Each kit includes heavy-duty inner and outer rod ends with a replacement boot, clamps, and any required lock washers. Outer tie rod ends are also available individually.

Included Items:

• (1) 12mm-1.25 right-hand thread tie rod end
• (1) 12mm-1.25 hex nut
• (1) 10mm-1.25 x 90mm hex head bolt
• (1) 10mm-1.25 nyloc nut
• (2) 10mm ID x 25mm OD flat washers
• (1) 12mm ID x 30mm OD flat washer
• (1) 14mm-1.50/12mm-1.25 right-hand thread rack end
• (1) Black rubber boot
• (2) 7 1/2 in. black plastic cable ties

Fitment List

Can-Am

• 2012 Can-Am Commander 1000 STD
• 2012 Can-Am Commander 1000 XT/LTD/DPS
• 2012 Can-Am Commander 800 STD
• 2012 Can-Am Commander 800 XT

Right Rack & Pinion Rebuild Kit
ALLBALLS 51-1047-R
Includes heavy-duty tie rod outer end and boot.
